12v20ah sealed maintenance free lead acid battery sealed maintenance free lead acid battery leoch battery

12v20ah sealed maintenance free lead acid battery sealed maintenance free lead acid battery leoch battery

Model NO.: 6-DZM-20
Price:: USD 2.00-27.00 / pieces
Delivery: FOB
Minimum order quantity: 200 pieces
Supply Ability: 12000 pieces / Day
Country of Origin: Shanghai,Ningbo,Shenzhen
Stock Time: 7-15days Days

Quantity:

Product Description

Place of Origin:CN;JIA
Nominal Voltage:12V
Brand Name:Xupai
Nominal Capacity:20AH
Model Number:6-DZM-20
Type:lead acid battery
Size:180*76*170mm

Product Description

20_1

20_3

20_2

12v-24-volt-20ah-Battery-for-electric

1111

222

Model	6-DZM-20	Nominal Voltage	12V	Rated Capacity	20AH
Type	Lead acid battery	Dimension	18076170mm	Weight	7.0kg
Certificate	ISO9001, ISO14001, CE, UL	MOQ	200pcs/item	Package Detail	Paper Carton with Wooden Pallet
Payment	T/T OR L/C is available

Main Product

Product parameters

Product Parameter :

XUPAI-Ebike Battery(DZM series )Model Specifiction

Model	Normal voltage (V)	Charge time (hr)	Rated Capacity (Ah)	Dimensions (±2mm)			Dimensions (in)			Weight
Model	Normal voltage (V)	Charge time (hr)	Rated Capacity (Ah)	L	W	H	L	W	H	Kg±0.5	lb
6- DZM- 12	12	2	12	151	100	99	5.94	3.94	3.90	4.30	9.48
6- DZM- 20	12	2	20	180	76	170	7.09	2.99	6.69	6.90	15.21
6- DZM- 22	12	2	22	180	76	170	7.09	2.99	6.69	7.10	15.65
6- DZM- 24	12	2	24	185	105	130	7.28	4.13	5.12	7.30	16.09
6- DZM- 28	12	2	28	175	166	125	6.89	6.54	4.92	9.80	21.61
6- DZM- 32	12	2	32	175	166	125	6.89	6.54	4.92	10.30	22.71
8- DZM- 14	16	2	14	201	112	102	7.91	4.41	4.02	7.00	15.43
8- DZM- 20	16	2	20	250	100	130	9.84	3.94	5.12	9.80	21.61

XUPAI-Electric road car Battery(EVF series) Model Specifiction

Model	Normal voltage (V)	Charge time(hr)				Dimensions (mm±2mm)				Dimensions (in)				Weight
Model	Normal voltage (V)	20hr	10hr	3hr	2hr	L	W	H	T/H	L	W	H	T/H	Kg	lb
6-EVF-32A	12	38	35	32	30	266	76	170	170	10.47	2.99	6.69	6.69	9.80	21.61
6-EVF-32B	12	38	35	32	30	223	93	175	175	8.78	3.66	6.89	6.89	9.80	21.61
6-EVF-38	12	45	42	38	35	223	108	175	175	8.78	4.25	6.89	6.89	11.80	26.01
6-EVF-40	12	50	45	40	35	223	120	175	175	8.78	4.72	6.89	6.89	12.30	27.12
6-EVF-45	12	55	50	45	40	223	120	175	175	8.78	4.72	6.89	6.89	13.40	29.54
6-EVF-50	12	60	55	50	45	223	135	177	177	8.78	5.31	6.97	6.97	15.00	33.07
6-EVF-55	12	65	60	55	48	230	150	180	180	9.06	5.91	7.09	7.09	16.50	36.38
3- EVF-180	6	210	200	180	160	260	180	270	275	10.24	7.09	10.63	10.83	33.50	73.85
3- EVF-200	6	230	220	200	180	260	180	270	275	10.24	7.09	10.63	10.83	36.00	79.37
3- EVF-200S	6	230	220	200	180	330	180	222	222	12.99	7.09	8.74	8.74	35.00	77.16
4- EVF-150	8	175	165	150	135	260	180	280	285	10.24	7.09	11.02	11.22	36.00	79.37
6- EVF-100	12	115	110	100	88	330	170	215	215	12.99	6.69	8.46	8.46	33.00	72.75
6- EVF-120	12	140	133	120	106	407	170	240	240	16.02	6.69	9.45	9.45	41.00	90.39
6- EVF-150	12	175	166	150	133	483	170	240	240	19.02	6.69	9.45	9.45	50.00	110.23
6- EVF-200	12	230	220	200	176	522	240	220	228	20.55	9.45	8.66	8.98	68.00	149.91

Features:

1)Eco-friendly batteries.

2)Ease of use - battery is easily replaced.

3)Maintenance free from battery storge.

4)Use ABS plastic shell and valve technology.

5)Long service life-cycle.

6)Specially designed with safe and secure features.

Applications:

1) E-bike,bicycle

2) Electric Rickshaw

3) Battery-powered wheelchairs

4) Golf trolleys

5) Ride-on toys

6) Electric scooters

7) Lawn mowers

8) T-walker

9) Electric tricycle

Xupai Brand Deep Cycle Lead Acid Battery
*Model*	Nominal Voltage/V	Discharge Time/Hrs	Rated capacity/AH	Dimensions(±1mm)	Weight /Kg(+/-50g)
*Model*	Nominal Voltage/V	Discharge Time/Hrs	Rated capacity/AH	LWH	Weight /Kg(+/-50g)
6-DZM-12	12	2	12	15110097	4.3
6-DZM-17	12	2	17	18076152	6.3
6-DZM-20	12	2	20	18076170	7
6-DZM-28	12	2	28	175166125	9.8
6-DZM-32	12	2	32	175166125	10.5
6-DZM-48	12	2	48	196164175	16
6-FM-35	12	10	35	26777170	10.2
6-FM-42	12	5	42	220120175	12.5
6-FM-50	12	10	50	224120177	13.35
8-DZM-14	16	2	14	201112102	7
8-DZM-20	16	2	20	250100130	9.6
8-DZM-28	16	2	28	230166125	12.7
